Product Details:
Payment & Shipping Terms:
|
| Product Name: | Air Operated Fluid Transfer Pump | Maximum Flow Rate: | 46 L/min |
|---|---|---|---|
| Feature: | Light And Small Size | Noise Level: | <70db |
| Highlight: | industrial diaphragm pump,sanitary diaphragm pump |
||
Stainless Steel Diaphragm Air Pumps Air flow For Sodium Hydroxide
Product Features
| 1 | Ceramic material for main valve and reversing valve ensures longer life, more stability and working in dirty compressed air ( most occasions, air filter become option). |
| 2 | Without ice with the muffler. Innovative design with the exhaust space of the pump, some of muffler inside, this makes the air outlet smooth.) |
| 3 | Outward parts of the pump are all die casted aluminum and special environment-protected painting, makes the pump with elegant appearance. |
| 4 | Large flow capacity. Innovative design of chamber maximizes the flow capacity. Seamless adjustment with inlet valve, or even close the valve, without damaging the pump. |
| 5 | Low consumption compressed air. Innovative design of the air flow system, minimizes the usage of compressed air to achieve maximum performance. |
| 6 | Light and small size, movable. |
| 7 | Modularization of main valve and air motor. No broken, easy to disassemble and repair. |
| 8 | Optimized design greatly reduces overall component number of pump. Significantly improve performance, help for maintenance. |
| 9 | For power variety, pneumatic pump’s flow capacity normally lowers than electric pump, but BSK pump is workable in series at certain conditions. This can largely satisfy customer request. |
| 10 | Innovated design of sealing structure and material, totally solve the leakage inside or outside. |
| 11 | BSK pump can be started with low air press ( only 1.5 KG air press can start BSK pump). |
| Item | Description | Unit | Reference Figure |
| 1 | Maximum air inlet pressure | Mpa | 0.69 |
| 2 | Maximum flow rate | l/Min | 46 |
| 3 | Maximum lift | M | 70 |
| 4 | Maximum outlet pressure | Mpa | 0.69 |
| 5 | Maximum particle size | mm | 2.5 |
| 6 | Weight | kg | 2.8 |
| 7 | Noise level | db | ＜70 |
A 2 5 X X - X X X - X (model selection)
Form of pipe mouth:A-BSP B-NPT(F) C-Flange
Diaphragm material:9 – Santoprene H – Hytrel T - PTFE/Santoprene
Ball material:9 -Santoprene H – Hytre T – PTFE A - Acetal
Ball seat material:P/K –Polypropylene/Kynoar SS –Stainless Steel
Pump material: SS –Stainless Steel AL –Aluminum Alloy CI- Carbon Steel P/K –Polypropylene/Kynoar
Maximum Applied Temperature Limits (diaphragm / ball / seal material)
Acetal ···················································· 40°- 150°F (4.4- 65.5°C)
Santoprene··············································-40°- 225°F (-40°- 107.2°C) ·······················································40°- 220°F (4.4°- 104°C) Nitrile························································10°- 180°F (-12°- 82°C) Viton························································-40°- 350°F (-40°-176.6°C) Hytrel························································-20°-150°F (-12°- 93°C) Kynar························································10°-200°F (-28.9°- 65.5°C) Polypropylene··············································32°- 175°F (0-79.4°C)
1" Flow diagram
Maintenance
