Air Operated Stainless Steel Diaphragm Pump / Air Double Diaphragm Pump

Air Operated Stainless Steel Diaphragm Pump / Air Double Diaphragm Pump
Air Operated Stainless Steel Diaphragm Pump / Air Double Diaphragm Pump Air Operated Stainless Steel Diaphragm Pump / Air Double Diaphragm Pump Air Operated Stainless Steel Diaphragm Pump / Air Double Diaphragm Pump

Large Image :  Air Operated Stainless Steel Diaphragm Pump / Air Double Diaphragm Pump

Product Details:
Place of Origin: China
Brand Name: BSK
Model Number: BSKA50SS-PTT-A
Payment & Shipping Terms:
Minimum Order Quantity: 10 Unit(s)
Price: Negotiable
Packaging Details: carton
Delivery Time: 7
Payment Terms: FOB T/T
Supply Ability: 1000 Unit(s) Per Month
Guarantee:: one year
Detailed Product Description
Product: Pneumatic Operated Diaphragm Pump Maximum Particle Size: 7mm
Application: Water Treatment Industry Feature: Non Leakage
Highlight:

stainless diaphragm pump

,

industrial diaphragm pump

SS Air Operated Double Diaphragm Vacuum Pump 8.3bar Self Priming





Air diaphragm pump(also know as a Membrane pump, air operated double diaphragm pump(AOOD) or pneumatic diaphragm pump)that uses a combination of the reciprocating action of a rubber,thermoplastic or diaphragm and suitable valves either side of the diaphragm (check valve,butterfly valves,flap valves,or any other form of shut-off valves) to pump a fluid.



Item Description Unit Reference Figure
1 Maximum air inlet pressure Mpa 0.83
2 Maximum flow rate L/Min 667
3 Maximum lift M 70
4 Maximum outlet pressure Mpa 0.83
5 Maximum particle size mm 7
6 Weight kg 28
7 Noise level db <70





Working Principle
In the two symmetrical pump chamber equipped with a diaphragm, which is connected by a center couplet stem. Compressed air comes in from pump inlet valve, and enter into one cavity, push the diaphragm movement, and gases emitted from another cavity. Once to the destination, gas distribution components will automatically compressed air into another chamber, push the diaphragm to the opposite direction, thus make two diaphragm continuous synchronization to reciprocating movement.

Compressed air goes into the valve, make the diaphragm to the right movement, and chamber suction make medium enter into, push the ball into the room, ball valve shuts down due to inhalation, Mediums discharged by extrusion, and opened the ball valve and at the same time close the ball valve, prevent back flow, thus to make medium ceaseless from the entrance inhaled, exit eduction.



Application area:
Chemical Industry; Coating Industry; Painting Industry; Dye Industry; Pigment and Textile Chemical Industry; Food Industry; Water treatment Industry; Petroleum Industry; Environmental protection Industry; Pharmaceutical Industry


Specifications



Air Diaphragm Pump
1. Non leakage
2. Good self priming performance
3. Convey all kinds of medium
4. Material:Cast steel,Alu,SS,PP





A 50 X X - X X X - X   (model selection)



Form of pipe mouth:A-BSP B-NPT(F) C-Flange

Diaphragm material:9 – Santoprene H – Hytrel   T - PTFE/Santoprene

Ball material:9 -Santoprene H – Hytre T – PTFE A - Acetal

Ball seat material:P/K –Polypropylene/Kynoar SS –Stainless Steel

Pump material: SS –Stainless Steel AL –Aluminum Alloy   CI- Carbon Steel P/K –Polypropylene/Kynoar



Maximum Applied Temperature Limits (diaphragm / ball / seal material)





Acetal ···············································40°-         150°F        (4.4- 65.5°C)

Santoprene·········································-40°- 225°F (-40°- 107.2°C)   ·················································40°- 220°F (4.4°- 104°C)   Nitrile··················································10°- 180°F (-12°- 82°C)   Viton···················································-40°- 350°F (-40°-176.6°C)   Hytrel··················································-20°-150°F (-12°- 93°C)   Kynar··················································10°-200°F (-28.9°- 65.5°C)   Polypropylene········································32°- 175°F (0-79.4°C)





2"  Flow diagram
